Fully retractable locators, these models mount directly through a member by a jam nut on the work side or flush by drilling and tapping the member. Locks in extended or retracted position. When flush mounted, plunger completely retracts from work area.

Part Number#:

DS 602

In stock

$27.22
-
+
Overview
PLUNGER CLAMP
Fully retractable locators, these models mount directly through a member by a jam nut on the work side or flush by drilling and tapping the member. Locks in extended or retracted position. When flush mounted, plunger completely retracts from work area. An optional base mounting detail is available for Model 604 as part no. 604106, and for Model 624 as part no. 624108. All models provided with an ergonomic handle grip. Also available with Metric Plunger thread.
More Information
Weight (lbs) 0.250000
Pack Size Each
UOM EA
Material Steel
Finish Zinc Plated
Mounting Flange
Load Capacity (lbs./pair) 200
Grease Fitting No
Type Straight Line Action
Size Small
